High Working Pressure Layflat Water Discharge Hose PVC Excellent Durability

    Buy cheap High Working Pressure Layflat Water Discharge Hose PVC Excellent Durability from wholesalers

    Buy cheap High Working Pressure Layflat Water Discharge Hose PVC Excellent Durability from wholesalers
    • Buy cheap High Working Pressure Layflat Water Discharge Hose PVC Excellent Durability from wholesalers

    High Working Pressure Layflat Water Discharge Hose PVC Excellent Durability

    Ask Lasest Price
    Brand Name : ASOE
    Model Number : Wovenflex Extra
    Certification : ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10000m per week
    Delivery Time : depends on your order quantity
    • Product Details
    • Company Profile

    High Working Pressure Layflat Water Discharge Hose PVC Excellent Durability


    6 inch PVC Lay Flat Frac Water Discharge Hose 14bar Working Pressure


    PRODUCT INTRODUCTION

    • Wovenflex Extra is one type of “through-the-weave” heavy duty PVC/NBR layflat hose.
    • This hose features a unique one-piece, through-the-weave construction and attains its higher working pressure from a synthetic woven polyester reinforcement than Spiral plies.
    • Its excellent durability is derived from a high-tensile PVC/NBR rubber compound, which completely encases the jacket.
    • The ribs on the the cover surface greatly increaseabrasion resistance.

    Inner tube and coverPVC/NBR compound, smooth cover, both tube and cover are co-extruded to obtain maximum bending.
    ReinforcementCircular woven polyester jacket
    Operating Temperature RangeF-37° C to 81° C)
    Standard ColorYellow, other colors available per request
    Standard Length50ft, 100ft, 300ft/91.5m, 330ft/100m; other lengths


    PRODUCT PARAMETER


    Nominal ID

    Wall thickness

    Weight

    Pressure rating

    Inches

    mm

    Inches

    mm

    lbs/ft

    kg/m

    psi/bar

    1 1/2"

    38

    0.09"

    2.2

    0.21

    0.31

    250psi/17bar, 200psi/14bar

    2"

    52

    0.11"

    2.7

    0.34

    0.51

    250psi/17bar, 200psi/14bar

    2 1/2"

    64

    0.12"

    2.9

    0.44

    0.66

    250psi/17bar, 200psi/14bar

    3"

    78

    0.12"

    3.0

    0.52

    0.78

    250psi/17bar, 200psi/14bar

    4"

    104

    0.13"

    3.2

    0.80

    1.19

    200psi/14bar, 150psi/10bar

    6"

    154

    0.16"

    3.9

    1.56

    2.33

    200psi/14bar, 150psi/10bar

    8"

    205

    0.17"

    4.4

    2.29

    3.41

    150psi/10bar

    10"

    255

    0.18"

    4.5

    3.05

    4.55

    150psi/10bar

    12"

    305

    0.18"

    4.5

    3.37

    5.03

    150psi/10bar


    PRODUCT APPLICATION


    • Water Discharge

    • Temporary installations (by-passes)

    • Construction

    • Irrigation


    Comparable to: Oroflex 10, Oroflex 20 etc.
